Network Segmentation of Linux VMs using KubeArmor

KubeArmor now enforces layer 3/4 network rules on Linux VMs via a new CRD: KubeArmorNetworkPolicy. Policies support CIDR ranges, port ranges, interface scoping, and both ingress and egress control. Enforcement runs at the kernel via nftables and is stateful by default.

The Gap That Hurt VM Security

KubeArmor already enforced process execution, file access, and protocol-level network syscalls on VMs. But layer 3 and layer 4 controls were missing. You could block a protocol, optionally filtered by process, but that was the ceiling.

You could not write: accept TCP on port 5432 only from this CIDR, on this interface. No ingress/egress port control. No IP block rules. No port ranges. KubeArmorNetworkPolicy closes that gap.

Network segmentation on Linux VMs has historically required either cloud security groups or a separately managed firewall tool. KubeArmor collapses both into a single policy plane that lives alongside your workload definitions.

In a segmented network, each VM zone (database tier, app tier, bastion) should only communicate with adjacent tiers on approved ports. Without kernel-level enforcement, those boundaries exist only on paper.

What Is the Network Policy Enforcer?

A new feature that adds layer 3/4 network enforcement to KubeArmor for VMs. It introduces a dedicated CRD, KubeArmorNetworkPolicy, separate from the three existing policy types.

CRD	Target	Enforcement Layer	Use When
KubeArmorPolicy	Containers / pods	Process, file, syscall, protocol+process	Container workload hardening
KubeArmorHostPolicy	VM / host	Process, file, syscall, protocol+process	Host-level process and file control
KubeArmorNetworkPolicy	VM / host nodes, K8s Nodes	Layer 3/4: CIDR, port, port range, interface	IP-based and port-based VM network control

Figure 1: KubeArmor policy CRD hierarchy and enforcement layers

Under the Hood: nftables

KubeArmor translates KubeArmorNetworkPolicy rules into nftables rules on the host. It creates its own table named KubeArmor, with chains that hook into Linux's input and output hooks. Every applied policy becomes a rule inside those chains.

Two default rules are always present in every chain:

• Loopback traffic is always allowed. Services communicating locally over lo are not disrupted.
• Established and related connections are accepted, making the policy stateful. An ingress allow does not require a matching egress rule for reply packets.

On startup, KubeArmor checks that nftables is present and running as root. If nftables is unavailable, the enforcer skips initialization. No silent failures.

Default Posture and Enabling the Feature

Setting	Behavior
Default posture: Block	Traffic not matched by any policy is dropped.
Default posture: Audit	Unmatched traffic is logged only. No blocking.
enableNetworkPolicyEnforcer: true (default)	Feature active. KubeArmorNetworkPolicy resources are enforced.
enableNetworkPolicyEnforcer: false	Feature disabled. Existing CRDs unaffected.

Policy Structure

The spec mirrors Kubernetes NetworkPolicy with two additions: an action field and an iface field. Anyone familiar with K8s network policies will read these without friction.

apiVersion: security.kubearmor.com/v1
kind: KubeArmorNetworkPolicy
metadata:
  name: [policy name]
spec:
  severity: [1-10]          # optional (appears in alerts)
  tags: ["tag", ...]        # optional (e.g., MITRE, STIG)
  message: [message]        # optional (injected into alert logs)
  nodeSelector:
    matchLabels:
      [key]: [value]        # target nodes by label
  ingress:
  - from:
    - ipBlock:
        cidr: [IP range]    # IPv4 or IPv6
    iface: [if1, ...]       # optional: scope to specific interfaces
    ports:
    - protocol: [TCP|UDP|SCTP]
      port: [number or name in string]
      endPort: [optional: defines a port range]
  egress:                   # mirrors ingress; uses 'to' instead of 'from'
  action: [Allow|Audit|Block]

Field	Required	Notes
nodeSelector	Yes	Standard K8s label selector. System labels (kubernetes.io/hostname) also valid.
ingress.from.ipBlock.cidr	No	Source IP range for inbound rules. IPv4 or IPv6.
egress.to.ipBlock.cidr	No	Destination IP range for outbound rules.
iface	No	Restricts rule to named interfaces. Ports/protocol apply only to listed interfaces.
port	No	Single port by number or name (ssh, dns, http, https).
endPort	No	If set, defines a range from port to endPort.
action	Yes	Allow, Block, or Audit.

Example Policies

Policy 1: Lock a VM to Its Private Network

A database VM in subnet 10.0.1.0/24 should only accept TCP connections from that subnet on port 5432. All other inbound TCP is blocked.

apiVersion: security.kubearmor.com/v1
kind: KubeArmorNetworkPolicy
metadata:
  name: allow-private-subnet-ingress
spec:
  nodeSelector:
    matchLabels:
      role: database
  ingress:
  - from:
    - ipBlock:
        cidr: "10.0.1.0/24"
    ports:
    - protocol: TCP
      port: "5432"
  severity: 7
  action: Block

Attack vector blocked: Lateral movement to database nodes. A compromised host outside the subnet cannot reach port 5432 even if cloud security groups are misconfigured.

This is the canonical micro-segmentation pattern: the database tier accepts connections only from the app tier CIDR, and nothing else. No firewall rule outside the VM can guarantee this if the cloud NSG drifts.

Policy 2: Block Outbound DNS to External Resolvers

Block UDP port 53 traffic to 8.8.8.8. Forces name resolution through internal DNS and closes the DNS tunneling C2 channel.

apiVersion: security.kubearmor.com/v1
kind: KubeArmorNetworkPolicy
metadata:
  name: block-external-dns
spec:
  nodeSelector:
    matchLabels:
      kubernetes.io/hostname: "prod-worker-01"
  egress:
  - to:
    - ipBlock:
        cidr: "8.8.8.8/32"
    ports:
    - protocol: UDP
      port: "dns"
  severity: 5
  action: Block

Attack vector blocked: DNS exfiltration and C2 callbacks via public resolvers. Leaves internal DNS resolution untouched.

Policy 3: SSH Restricted to Jump Host (Progressive Enforcement)

SSH access to production VMs should only originate from the corporate jump host subnet (192.168.10.0/28). Use a two-policy pattern: audit broadly first to baseline, then block.

Policy A — Audit all SSH globally:

apiVersion: security.kubearmor.com/v1
kind: KubeArmorNetworkPolicy
metadata:
  name: audit-ssh-all
spec:
  nodeSelector:
    matchLabels:
      env: production
  ingress:
  - from:
    - ipBlock:
        cidr: "0.0.0.0/0"
    ports:
    - protocol: TCP
      port: "ssh"
  message: "SSH from outside jump host subnet detected"
  severity: 8
  action: Audit

SSH access control is a segmentation boundary, not just an access policy. Restricting it by source CIDR enforces the separation between the management plane and the data plane at the host level.

Policy B — Allow only the jump host subnet:

apiVersion: security.kubearmor.com/v1
kind: KubeArmorNetworkPolicy
metadata:
  name: allow-ssh-jumphost
spec:
  nodeSelector:
    matchLabels:
      env: production
  ingress:
  - from:
    - ipBlock:
        cidr: "192.168.10.0/28"
    ports:
    - protocol: TCP
      port: "ssh"
  severity: 2
  action: Allow

The message field in Policy A surfaces directly in alert logs for SIEM ingestion. Run Audit for 48 hours, validate there are no false positives, then flip to Block.

Policy 4: Interface-Scoped Port Range for Backend Service Mesh

A VM with two NICs: eth0 for external traffic, eth1 for internal service mesh. Restrict inbound traffic on eth1 to ports 8000–9000 from the internal CIDR only. eth0 is unaffected.

apiVersion: security.kubearmor.com/v1
kind: KubeArmorNetworkPolicy
metadata:
  name: restrict-backend-mesh
spec:
  nodeSelector:
    matchLabels:
      tier: backend
  ingress:
  - from:
    - ipBlock:
        cidr: "172.16.0.0/12"
    iface: ["eth1"]
    ports:
    - protocol: TCP
      port: "8000"
      endPort: 9000
  severity: 6
  action: Block

Use iface to prevent over-broad rules from affecting unrelated traffic paths. Common in hybrid cloud and service mesh deployments where VMs have separate NICs per traffic class.

How It Fits Into a Zero Trust VM Architecture

Traditional network policies (cloud security groups, NSGs) operate at the cloud perimeter. They do not enforce on the VM itself. KubeArmorNetworkPolicy enforces at the kernel via nftables, which means:

• Policy follows the workload, not the infrastructure boundary.
• Rules hold even if cloud-level security groups are misconfigured or bypassed.
• Works in air-gapped, hybrid, or bare-metal deployments with no cloud networking controls.

Combined with KubeArmor's process and file policies, you get defense-in-depth on every VM. A compromised process cannot make unauthorized outbound calls. An attacker who lands on the VM cannot reach internal services or external C2 if those paths are explicitly blocked.

Micro-segmentation means each VM enforces its own perimeter. KubeArmor achieves this without a separate network appliance or agent: the nftables rules live on the host itself and survive cloud perimeter changes.

Getting Started

The Network Policy Enforcer is enabled by default in recent KubeArmor releases.

Verify the enforcer is active on your nodes:

kubectl get kubearmornodestatus \
  -o jsonpath='{.items[*].status.networkPolicyEnforcer}'

Apply a policy:

kubectl apply -f nsp-allow-private-subnet-ingress.yaml

Inspect generated nftables rules on the host:

sudo nft list table ip kubearmor

Policy violations appear in KubeArmor alerts. Pipe the message field into your SIEM for contextualized incident tickets.

References

• KubeArmor Network Policy Specification
• KubeArmor Network Policy Examples
• Network Policy Enforcer Guide
• KubeArmor GitHub

Frequently Asked Questions

Does KubeArmorNetworkPolicy replace KubeArmorHostPolicy?

No. They are complementary. KubeArmorHostPolicy handles process execution, file access, and protocol-level syscall controls on the VM host. KubeArmorNetworkPolicy handles CIDR, port, and interface rules at the network layer. Use both together for full depth.

Does this work on distributions that still use iptables?

KubeArmor uses nftables, which ships by default on major Linux distributions (Ubuntu 20.04+, RHEL 8+, Debian 10+). On older distributions it is not pre-installed but can be manually installed on any system running Linux kernel 3.x+. On startup, KubeArmor checks for nftables availability. If nftables is present and KubeArmor is running as root, it initializes. iptables is not used by the Network Policy Enforcer.

Can I define both ingress and egress rules in a single policy?

Yes. A single KubeArmorNetworkPolicy spec can contain both ingress and egress blocks. Define them independently with their own CIDR, interface, and port values.

What happens to traffic that does not match any policy?

The behavior depends on your default network posture configuration. When running in allowlist mode (at least one allow-based policy is active), unmatched traffic follows the default posture — dropped if set to Block, or logged and allowed through if set to Audit. Outside of allowlist mode, unmatched traffic is recorded in host logs. Set your default posture explicitly before deploying Block-action policies to production.

How is this different from a standard Linux firewall like ufw or firewalld?

KubeArmor network policies implement micro-segmentation across a fleet of VMs declaratively, with the same GitOps workflow you already use for application policies. ufw and firewalld are standalone firewall managers with no policy-as-code workflow, no Kubernetes API surface, and no integration with workload identity or labels. KubeArmorNetworkPolicy uses the same nftables kernel layer but is declared as a Kubernetes CRD, version-controlled, auditable, and scoped by node labels. It is also stateful by default and composable with process and file policies from the same agent.
